FlexStor
FlexStor is Gluesys’s next-generation NAS solution built on the ZFS file system,
offering exceptional data protection, high-performance I/O,
and reliable file services.
System configuration


Fast & Reliable Enterprise Network Storage

Logical Disk Management with RAIDZ
Filesystem-Level Caching Mechanism


Hardware Redundancy Architecture
LACP


COW-Based Snapshots
Local & Remote Replication


Secure Data Encryption
Data Integrity Verification


Multi-Protocol Support
Web-Based File Manager


Inline Data Compression
Active Directory Integration


Flexa Manager
Intelligent Performance & Health Monitoring


Storage Management API




Use Cases
File Sharing
Organizations are now consolidating business data generated
from PCs and departments to a centralized storage system to
eliminate storage silos and enhance work efficiency.
AnyStor delivers file storage service to heterogeneous servers and
clients with flexibility and cost-effectiveness, especially for small and
medium enterprises. AnyStor can also be used as a NAS gateway
to provide file services in a block storage environment.
Use Cases
Data Recovery
IT infrastructures are constantly exposed to the risk of data loss
from unpredictable instances, such as system failure and
ransomware, which can cause substantial damage to the
organization's business.
AnyStor Backup and Recovery system
provides maximum availability and stability to your storage infrastructure.
AnyStor expansion model delivers massive write speed and
tape compatibility, which is perfect for primary backup storage.
AnyReplicator is an exclusive disaster recovery solution for AnyStor
to deploy remote and local disaster recovery system that can easily
recover the entire configuration and data in real-time.
Use Cases
High Availability Services
System failures can cause a huge financial loss, especially for
online transaction services and security-sensitive applications that
goes on day and night. As a result, organizations implement
failover systems to secure service uptime and reduce data loss
from a possible threat.
AnyStor NAS Gateway allows mission-critical
services to be delivered without disruption through failover clustering.
If an active node fails, AnyStor instantly activates the backup node to
resume the service.
Use Cases
Virtual Storage Environment
Organizations that run mission-critical application services
in a virtualized environment wants to secure accessibility and
availability of VM images to pull out the best performance and
agility from their application.
AnyStor All-Flash Storage accelerates
your virtualized environment under massive random workloads
while attaining high I/O performance and system availability.
PRODUCT LINEUP
Dual Controller
F724DC | F524DC | F560DC | F590DC | |
---|---|---|---|---|
Media Type | NVMe SSD | SAS SSD | SAS SSD | SAS SSD |
Form Factor | 2U | 4U | 4U | 4U |
Processor | 2 x Intel Xeon | 2 x Intel Xeon | 2 x Intel Xeon | 2 x Intel Xeon |
Memory | 128GB | 128GB | 128GB | 128GB |
Max. Memory | 4TB | 4TB | 4TB | 4TB |
Bays | 24(2.5″) | 24(2.5″) | 60(2.5″) | 90(2.5″) |
Max. Physical Capacity | 737.28TB | 368.64TB | 921.6TB | 1.38PB |
Scale-up | – | Support | Support | Support |
E324DC | E360DC | E390DC | |
---|---|---|---|
Media Type | SAS HDD | SAS HDD | SAS HDD |
Form Factor | 4U | 4U | 4U |
Processor | 2 x Intel Xeon | 2 x Intel Xeon | 2 x Intel Xeon |
Memory | 64GB | 64GB | 64GB |
Max. Memory | 4TB | 4TB | 4TB |
Bays | 24(2.5″/3.5″) | 60(2.5″/3.5″) | 90(2.5″/3.5″) |
Max. Physical Capacity | 576TB | 1.44PB | 2.16PB |
Scale-up | Support | Support | Support |
PRODUCT LINEUP
Single Controller
F724SC | F524SC | F500SC* | |
---|---|---|---|
Media Type | NVMe SSD | SAS/SATA SSD | SAS/SATA SSD |
Form Factor | 2U | 2U | 1~4U |
Processor | 2 x Intel Xeon | 2 x Intel Xeon | 2 x Intel Xeon |
Memory | 128GB | 128GB | 128GB |
Max. Memory | 4TB | 4TB | 4TB |
Bays | 24(2.5″) / 16(E3.S) | 24(2.5″) | 4~Max. 90(2.5″) |
Max. Physical Capacity | 737.28TB | 368.64TB | 1.38PB |
Scale-up | – | Support | Support |
E312SC | E324SC | E300SC* | |
---|---|---|---|
Media Type | SAS/SATA HDD | SAS/SATA HDD | SAS/SATA HDD |
Form Factor | 2U | 2U | 1~4U |
Processor | 1~2 x Intel Xeon | 1~2 x Intel Xeon | 1~2 x Intel Xeon |
Memory | 64GB | 64GB | 64GB |
Max. Memory | 4TB | 4TB | 4TB |
Bays | 12(3.5″) / 16(2.5″) | 24(3.5″) | 4~Max. 90(2.5″/3.5″) |
Max. Physical Capacity | 288TB | 576TB | 2.16PB |
Scale-up | Support | Support | Support |
